How to connect double control switches? Double control and multi control switch physical wiring diagram first introduce a single open dual control switch as shown. The double control switch is also called a single knife and double throw switch. It has a public end L. No matter where the switch is, the ...mon end will always have two L 1 or more.
双控开关如何接线?双控和多控开关实物接线图
How to connect double control switches? Double control and multi control switch physical wiring diagram.
先介绍一下单开双控开关如图。
First, a single open double control switch is described.
双控开关如何接线?双控和多控开关实物接线图
How to connect double control switches? Double control and multi control switch physical wiring diagram.
双控开关又叫单刀双掷开关。它有一个公共端L 。不管开关在什么位置上，公共端总会与另两个端头L 1或L2的其中一个是接通的。按动开关，公共端就会与接合的那个端头断开，并和另一个端头接通。
The double control switch is also called a single knife and double throw switch. It has a public end L. No matter where the switch is located, the public terminal will always connect to one of the other two terminals, L 1 or L2. By pressing the switch, the ...mon end will be disconnected from the joint end and connected to the other end.
双控开关如何接线?双控和多控开关实物接线图
How to connect double control switches? Double control and multi control switch physical wiring diagram.
清楚了开关的原理。再看电路的原理就很简单了。因为双控开关的公共端总会与另两个端口的其中一个总是接通的，如上图，在客厅和卧室同时要控制客厅的灯，此时客厅灯不亮的，如果按下客厅和卧室的任何一个开关，电路都会导通灯亮。按图接线，在客厅的双控开关的公共端L 接火线。L 1、L 2引两根电线到卧室的双控开关，同样也接到L1、L2上。从卧室开关的公共端L接根线到灯头，灯头的另一端接零线即可。
It clears the principle of the switch. It's very simple to look at the principle of the circuit. Because the ...mon end of the double control switch will always connect with one of the other two ports, as in the drawing room and the bedroom to control the living room lights at the same time. At this time, the living room lights are not bright. If you press the living room and any one of the bedrooms, the circuit will turn on the light. According to the wiring diagram, the L of the ...mon end of the double control switch in the living room is connected with the fire line. L 1 and L 2 lead two wires to the double control switch in the bedroom, and also receive L1 and L2. From the ...mon end of the bedroom switch, L connects the root line to the lamp holder, and the other end of the lamp holder is connected to the zero line.
双控开关如何接线?双控和多控开关实物接线图
How to connect double control switches? Double control and multi control switch physical wiring diagram.
看到这里应该明白了吧。
It should be understood here.
多控就是在三个甚至更多的地方控制一盏灯。先看原理图。
Multi control is to control a lamp in three or more places. Look at the schematic first.
双控开关如何接线?双控和多控开关实物接线图
How to connect double control switches? Double control and multi control switch physical wiring diagram.
多控电路两端的K1和K3都是单开双控，中间的是双联双控开关，也叫一开多控开关，其实就是两个单开双控的复合体。它的正反面外观如图。
The K1 and K3 at both ends of the multi control circuit are both single open and double controlled. The middle is double double control switch, also called a multi control switch. In fact, it is the two single open double control ...plex. It has a positive and negative appearance.
双控开关如何接线?双控和多控开关实物接线图
How to connect double control switches? Double control and multi control switch physical wiring diagram.
L1 、L 11、L 12、是一组双控开关。L2、L21、L22、是一组双控开关。按下开关时两组开关同时动作。其外部用导线将L11和L22、L 12和L21、连接。这样无论原理图上的K1和K3在什么样的开关位置，按下中间的K2，电路都会接通。
L1, L 11, L 12, is a set of double control switches. L2, L21, L22, is a set of double control switches. When the switch is pressed, the two sets of switches are operated at the same time. The outer wires connect L11 to L22, L 12 and L21. So no matter what kind of switch location K1 and K3 are on the schematic and press the K2 in the middle, the circuit will be connected.
双控开关如何接线?双控和多控开关实物接线图YFFB扁电缆YFFB起重机扁电缆
How to connect double control switches? Double control and multi control switch physical wiring diagram.
多控开关的接线有点绕人。一定要看懂原理图。多模拟几个开关在不同位置，线路的通断。
The connection of the multi control switch is a bit around. Be sure to understand the schematic. It simulates the on-off of several switches at different locations.
双控开关如何接线?双控和多控开关实物接线图
How to connect double control switches? Double control and multi control switch physical wiring diagram.
超过三个地方控制一盏灯的电路图。原理都是一样，就是多串了几个单开多控开关。
There are more than three places to control the circuit diagram of a lamp. The principle is the same, that is, there are several single open multi control switches.
最后大家比较一下两种一开多空开关的接线有什么不同。YFFB扁电缆YFFB起重机扁电缆
Finally, let's ...pare the wiring between two kinds of open and close switches.
